完全拆卸并清洁散热器（热泵） (Maintenance)

校正代码 18301200 1.20 注意：除非本程序中另有明确规定，否则上文所列校正代码和 FRT 反映的是执行本程序（包括关联程序）所需的所有工作。除非明确要求，否则请勿堆叠校正代码。 注意：请参阅平均维修工时深入了解 FRT 及其创建方式。 注意：请参阅人员保护确保在执行以下程序时穿戴适当的个人防护装备 (PPE)。 注意：请参阅人体工程学注意事项查看安全健康的作业规程。

警告
本程序为“草案”。虽已通过验证，但可能仍有“警告”和“注意”事项缺失。请遵守安全要求，处理或靠近高压系统和部件时，请谨慎操作。
  • 2026-08-12: Added the PROC_VC_X_RESET-RADIATOR-UA-INDEX routine.
  • 2026-04-21: Released new procedure.
  1. Raise and support vehicle
    注
    Ensure vehicle is not charging.
  2. Open LH front door and lower the LH front window.
  3. Remove the radiator. See 散热器 ((拆卸和更换)).
  4. Use a vacuum to clean debris from both sides of the radiator.
    注
    Do not damage fins of radiator.
  5. Use a blow gun to clean both side of the radiator with compressed air.
    注
    Do not damage fins of radiator.
  6. Install the radiator. See 散热器 ((拆卸和更换)).
  7. Connect a laptop with Toolbox to the vehicle. See Toolbox（连接和断开）.
  8. 运行 ODIN 例行程序 PROC_VC_X_RESET-RADIATOR-UA-INDEXvia Toolbox:(link)
    注
    Perform this step for firmware versions develop/2026.14.3 and later.
  9. 运行 ODIN 例行程序 TEST-SELF_VCFRONT_X_THERMAL-PERFORMANCEvia Service Mode:Thermal ➜ Actions ➜ Test Thermal Performancevia Service Mode Plus:
    • Drive Inverter ➜ Front Drive Inverter Replacement ➜ Thermal System Test
    • Drive Inverter ➜ Rear Drive Inverter Replacement ➜ Thermal System Test
    • Drive Inverter ➜ Rear Left Drive Inverter Replacement ➜ Thermal System Test
    • Drive Inverter ➜ Rear Right Drive Inverter Replacement ➜ Thermal System Test
    • Drive Unit ➜ Front Drive Unit Replacement ➜ Thermal System Test
    • Drive Unit ➜ Rear Drive Unit Replacement ➜ Thermal System Test
    via Toolbox:(link)
  10. Disconnect the laptop from the vehicle.
  11. Exit Service Mode Plus. See 维护模式增强版.
  12. Raise the LH front window and close the LH front door.
  13. Remove the vehicle from the lift.
